GM-38 / GM-27 Medium Shell Stitch Overlock Sewing Machine

The GM-38 and GM-27 are specialized overlock sewing machines designed to create high-quality shell-shaped decorative borders. By adjusting the stitch selection lever, operators can easily switch between 3 distinct knitting patterns (1-stitch, 4-stitch, and 8-stitch combinations) to suit various fabrics and design requirements.

Enquire for Price Brochure (PDF)

Need more information?

Our technical team is ready to help you choose the right machinery for your production needs.

Detailed Description

These shell stitch overlock sewing machines are highly adaptable industrial units that can produce multi-style shell-shaped decorative edges by matching different threads, cloth types, and needle gauges. They are engineered to provide elegant finishes and durable edging on a wide range of textile products.

Applications

The machines are ideally suited for sewing decorative borders on:

Sweaters and Coats
Fashionable Dresses and Robes
Blankets and Cushions
Towels, Slippers, and more

Technical Specifications

Specification	GM-38 (Large Shell Stitch)	GM-27 (Medium Shell Stitch)
Sewing Speed	1200 s.p.m	1200 s.p.m
Stitch Length	10–20 mm	10–15 mm
Stitch Width	10–12 mm	7–9 mm
Height of Presser Foot	6 mm	6 mm
Needle Type	DM x5	DM x5
Max. Power Consumption	370/250V	370/250V
Pole Type	AP / 4P	4P

Specification

GM-38 (Large Shell Stitch)

GM-27 (Medium Shell Stitch)

Sewing Speed

1200 s.p.m

Stitch Length

10–20 mm

10–15 mm

Stitch Width

10–12 mm

7–9 mm

Height of Presser Foot

6 mm

Needle Type

DM x5

Max. Power Consumption

370/250V

Pole Type

AP / 4P

Key Features

Versatile Stitch Finishes: Capable of producing three different combinations of edge finishes, including 1-stitch, 4-stitch, or 8-stitch configurations.

Easy Pattern Switching: Features a user-friendly stitch adjustment lever to effortlessly shift between the 3 distinct knitting styles.

High Adaptability: Easily adjusts to accommodate diverse thread types, fabric weights, and needle gauges for custom design outputs.
